Dimension (Optional)

Axle No.

Rated Load (kg)

Tire No.

Tire Size

20ft

2

40000

8

825R20 1000R20 1100R20 1200R20

12R22.5 (Other Size/ Single Super

Tire Contact with Supplier)

First Axles Air Lifting System Optional

40ft 45ft 48ft 53ft

3

60000

12

40ft 45ft 48ft 53ft

4

75000

16

Wheel Base (mm)

1310

leaf-spring Pcs

10

Axle

13/ 16/ 18 T

Suspension

Heavy Duty Mechanic Suspension with Leaf Springs

Main Beam Material

Q345B manganese plates, automatic submerged arc welded

Brake System

Dual line braking system with automatic braking system/ chambers

Brake Air Chamber

Double Model

Kingpin

2' or 3.5' Interchangeable

Landing gear

28 T loading capacity with 80 T static lifting capacity.

Platform

4-6 mm diamond steel plate

Brake System

Dual Lines Braking System With Automatic Air Chambers

Brake Air Chamber

Four double and two single chambers

Electrical System

24 V, 7 core socket, lights according to European standards.

Main beam Size

Upper plate

14 mm

Lower plate

16 mm

Mid Web

8 mm

Height

500-520 mm

Tool Box

1 box of standard tools

Spare tire carrier

2 sets

Color and Logo

Depends on the buyer’s requirement.

Pin Height

According to the height of the tractor saddle.

Painting

Three coats painting; Any color will be available

Application

For animal/ livestock/ coal/ grain bulk cargo transport

Box Height

2 M
